1989-1993 Ford E4OD Transmission Reference Manual PTB-201 F-Series Bronco

Price $59.00 $47.20 Details W: 11.25 x H: 11.5 x D: 3 Weight 6.75 lbs. Page Count 250+ Condition Used Original - Good Item Type Promotional Material Inventory Number SM-56157 OEM Number PTB-201 89-93
Flat US shipping rate: $19.95
Flat International shipping rate: $116.00

---

Description

1989-1993 Ford E4OD Transmission Reference Manual PTB-201. Original. This manual supercedes TSTS 1705-204 and adds 1992 and 1993 model years.

Looks as though it is applicable to the 1989-1993 Ford F-Series (F150-F450), Econoline (E150-E350), Bronco and F-Super Duty Motorhome.

Sections:
Theory/Operation

The Ford E4OD transmission is a fully automatic, electronically controlled four-speed unit with a three-element locking torque converter. The main operating components of the E4OD transmission include a converter clutch, six multiple-disc friction clutches, one band, two sprag one-way clutches and a roller one-way clutch providing the desired function of the three planetary gearsets.

Diagnosis by Symptom

The E4OD diagnostic charts follow a new format. The enhanced format is used to separate electrical from mechanical causes or concerns.

Diagnostic Procedures

The E4OD transmission is a fully automatic, electronically controlled, four-speed unit with a locking torque converter. The main operating components of the E4OD transmission include a converter clutch, six multiple-disc friction clutches, one band, two sprag one-way clutches and a roller one-way clutch which provide for the desired function of three planetary gearsets.

In-Vehicle Service

When fluid leakage is found at the oil cooler, the cooler must be replaced.

Disassembly/Reassembly

The flip chart pictorially illustrates step-by-step disassembly and assembly procedures of the E4OD Automatic Transmission. The use of special tools, when required, has been identified in the procedural step involved.

Sub-Assembly

Specifications

TSS/Oasis

Oasis Codes

Glossary

Out of Stock.
