1997 Ford F-150 F-250 Pickup Electrical Wiring Diagrams Manual

Price $69.00 $55.20 Details W: 11 x H: 8.5 x D: 0.875 Weight 1.62 lbs. Page Count 275+ Condition Used Original - Fair Item Type Factory Manual Inventory Number SM-55995 OEM Number FCS-12263-97-R In Stock
Flat US shipping rate: $8.95
Flat International shipping rate: $34.00
Description

1997 Ford F-150 and F-250 Pickup Electrical Wiring Diagrams Manual. ORIGINAL. Ford Authorized Manual.

Detailed wiring schematics, illustrations and component descriptions developed by Ford Motor Company. Information contained in each vehicle specific manual, has been developed to aid technicians in diagnosing and repairing vehicle wiring and electrical systems. Each manual covers connectors, component location and testing.

Years/Models Covered
1997 / F-150 Pickup / F-250 Pickup

Keywords: F-150, 4.2L, 4.6L, 5.4L

Condition: Service Manuals are used in Dealership Shops, Independent Garages and in Fleet Environments and thus can reflect such use, most often showing extensive signs of soiling, age, and wear. The information within is still legible and can give valuable insight. The images shown are representative of what is shipped.
