2000-2004 Ford 4F50N Transaxle Reference Manual PTB 402 Taurus Windstar Freestar

Price $59.00 $47.20 Details W: 12.5 x H: 11.75 x D: 4 Weight 8.69 lbs. Page Count 676 Condition Used Original - Good Item Type Promotional Material Inventory Number SM-56155 OEM Number PTB 402 In Stock
Flat US shipping rate: $24.95
Flat International shipping rate: $129.00

---

Description

2004 Ford 4F50N Transaxle Reference Manual PTB 402. Ford Taurus/Mercury Sable,  Ford Windstar, Freestar/Mercury Monterey. Original.

Looks as though the 4F50N transaxle was used in the Ford Taurus/Mercury Sable (2000-2004) with 3.0L 2V and 3.0L 4V engines, Ford Windstar (2001-2003) with 3.8L 2V engine, and Ford Freestar/Mercury Monterey (2004) with 3.9L and 4.2L engines.

Sections:
Theory/Operation

The Ford 4F50N automatic transaxle is a four-speed unit with electronic shift control. It is designed for operation in a transverse powertrain for front-wheel drive vehicles.
The 4F50N transaxle features a four-element torque converter design that includes Torque Converter Clutch (TCC) and a gear train.
The hydraulic control system of the 4F50N transaxle has electronically controlled solenoids.

Diagnostic Procedures

Troubleshooting an electronically controlled automatic transaxle is simplified by using the proven method of diagnosis. One of the most important things to remember is that there is a definite procedure to follow.

Diagnosis by Symptom

The Diagnosis By System Charts give the technician diagnostic information and direction. Each chart suggests possible components, using a symptom as a starting point.

Disassembly

This section pictorially illustrates step-by-step disassembly procedures for the Ford 4F50N transaxle. The use of special tools, when required, has been identified in the procedural steps involved.

Sub-Assembly

This section pictorially illustrates step-by-step sub-assembly procedures for the Ford 4F50N transaxle. The use of special tools, when required, has been identified in the procedural steps involved.

Reassembly

This section pictorially illustrates step-by-step reassembly procedures for the Ford 4F50N transaxle. The use of special tools, when required, has been identified in the procedural steps involved.

Special Tools

Lists special service tools, gives illustrations, part numbers and descriptions.
