2006 Ford 6R60 Transmission Reference Manual PTB 601 Explorer Mountaineer 4.6L

Price $59.00 $47.20 Details W: 12.5 x H: 11.75 x D: 4.125 Weight 6.00 lbs. Page Count 438 Condition Used Original - Good Item Type Promotional Material Inventory Number SM-56152 OEM Number PTB 601 In Stock
Flat US shipping rate: $19.95
Flat International shipping rate: $116.00
Description

2006 Ford 6R60 Transmission Reference Manual PTB 60. Ford Explorer, Mercury Mountaineer 4.6L. Original.

The Ford 6R60 transmission is a unit with six gear ratios and electronic shift control. The transmission is designed for operation in longitudinal powertrains for two-wheel and four-wheel drive rear-wheel drive vehicles.

Looks as though it is applicable to the 2006 Ford Explorer and 2006 Mercury Mountaineer.

Sections:
Theory/Operation

The 6R60 transmission features a four-element torque converter (TCC) and a gear train that has two planetary gearsets.

Diagnostic Procedures

Troubleshooting an electronically controlled automatic transaxle is simplified by using the proven method of diagnosis. One of the most important things to remember is that there is a definite procedure to follow.

Diagnosis by Symptom

The Diagnosis By System gives the technician diagnostic information and direction. It suggests possible components, using a symptom starting point. All routines start with any potential electrical components that can cause or contribute to the symptom described. The routines then list all possible hydraulic or mechanical components that can cause or contribute to the symptom described.

Disassembly

This section pictorially illustrates step-by-step disassembly procedures for the Ford 6R60 transmission. The use of special tools, when required, has been identified in the procedural steps involved.

Sub-Assembly

This section pictorially illustrates step-by-step sub-assembly procedures for the Ford 6R60 transmission. The use of special tools, when required, has been identified in the procedural steps involved.

Reassembly

This section pictorially illustrates step-by-step reassembly procedures for the Ford 6R60 transmission. The use of special tools, when required, has been identified in the procedural steps involved.

Special Tools

Lists special service tools, gives illustrations, part numbers and descriptions.
